Cutting Rules

Medical box, Luxury Cosmetic box

Our Recommendation　
Type SG、Type F、Type S、Type E

Characteristics　
Packaging for pharmaceutical products manufactured in clean rooms must be free of burrs and have clean cut edges.

Share：

inquiry

Specification
Specification

Type F - Infinity Cut (RO)

・Unique round edge provides beyong 2 million cuts.
・Long-lasting performance.
・Save time and cost from replacing rule again and again.

Applications:
Medicine box, Cigarette box, Cosmetics box

Super Ground Rule

TYPE	SG
Bevel type	CB (Center bevel) , LCB (Long center bevel)
Thickness	0.53mm (1.5pt)、0.71mm (2pt)、1.06mm (3pt)
Height	23.60mm (.929"), 23.80mm (.937")
Angle	∠42°、52°
Body hardness	HV320,340,380,400,450 / HRC32,34,38,40,45
Edge hardness	HV600,640,670,700 / HRC55,58,59,60

Infinity Cut

TYPE	F
Bevel type	CB (Center bevel) / LCB (Long center bevel)
Thickness	0.71mm (2pt)、1.06mm (3pt)
Height	23.60mm (.929"), 23.80mm (.937")
Angle	∠42°、52°
Body hardness	HV320,340,380,400,450 / HRC32,34,38,40,45
Edge hardness	HV600,640,670,700 / HRC55,58,59,60

Side Bevel Rule

TYPE	S
Bevel type	SB (Side bevel) , LSB (Long Side bevel)
Thickness	0.71mm (2pt)、1.06mm (3pt)、1.42mm (4pt)
Height	23.60mm (.929"), 23.80mm (.937")
Angle	∠42°、51°、52°
Body hardness	HV320,340,380,400,450 / HRC32,34,38,40,45
Edge hardness	HV600,640,670,700 / HRC55,58,59,60

Creasing Rule

TYPE	E
Bevel type	DR (Double Round) / SR (Single Round) / SF (Special facet)
Thickness	0.71mm (2pt)、1.06mm (3pt)、1.42mm (4pt)
Height	22.80mm (.897"), 23.10mm(.909")
Body hardness	HV320,340,380,400,450 / HRC32,34,38,40,45
