Cutting Rules

Cigarette box, Pillbox

Our Recommendation
Type SG、Type GR、Type F、Type E

Characteristics　　
・High rigidity, burst resistance, smoothness and whiteness, smooth paper surface
・The wrapper is strong and has enough protection to protect the drug from external physical damage such as impact, shock, and pressure.

Share：

inquiry

Feature
Specification

Type E - Creasing Rule

・Excellent radius profile.
・Very smooth creasing head.
・Minimum height tolerance.

Applications:
Packaging Containers, Plastic Boxes and Blisters.

Super Ground Rule

TYPE	SG
Bevel type	CB (Center bevel) , LCB (Long center bevel)
Thickness	0.53mm (1.5pt)、0.71mm (2pt)、1.06mm (3pt)
Height	23.60mm (.929"), 23.80mm (.937")
Angle	∠42°、52°
Body hardness	HV320,340,380,400,450 / HRC32,34,38,40,45
Edge hardness	HV600,640,670,700 / HRC55,58,59,60

Ground Rule

TYPE	GR
Bevel type	CB (Center bevel) , LCB (Long center bevel)
Thickness	0.45mm (1.27pt)、0.53mm (1.5pt)、0.71mm (2pt)、1.06mm (3pt)、1.42mm (4pt)
Height	23.60mm (.929"), 23.80mm (.937")
Angle	∠42°、52°
Body hardness	HV320,340,380,400 / HRC32,34,38,40
Edge hardness	HV600,640,670,700 / HRC55,58,59,60

Infinity Cut

TYPE	F
Bevel type	CB (Center bevel) / LCB (Long center bevel)
Thickness	0.71mm (2pt)、1.06mm (3pt)
Height	23.60mm (.929"), 23.80mm (.937")
Angle	∠42°、52°
Body hardness	HV320,340,380,400,450 / HRC32,34,38,40,45
Edge hardness	HV600,640,670,700 / HRC55,58,59,60

Creasing Rule

TYPE	E
Bevel type	DR (Double Round) / SR (Single Round) / SF (Special facet)
Thickness	0.71mm (2pt)、1.06mm (3pt)、1.42mm (4pt)
Height	22.80mm (.897"), 23.10mm(.909")
Body hardness	HV320,340,380,400,450 / HRC32,34,38,40,45
